HSK63 WEINIG MILLING ARBORS
in various lengths with shaft diameters:
- 20mm
- 30mm
- 40mm
- 50mm
For holding milling tools. Hardened, hard-turned, balanced.
Scope of delivery: with milling cutter tightening screw.
| Cone | D | DKT | L1 | L2 | L3 | Article Number |
|---|---|---|---|---|---|---|
| HSK63 Weinig | 20mm | 32mm | 128mm | 26mm | 70mm | FDHSK63WE02607020 |
| HSK63 Weinig | 30mm | 48mm | 98mm | 26mm | 40mm | FDHSK63WE02604030 |
| HSK63 Weinig | 30mm | 48mm | 108mm | 26mm | 50mm | FDHSK63WE02605030 |
| HSK63 Weinig | 30mm | 48mm | 138mm | 26mm | 80mm | FDHSK63WE02608030 |
| HSK63 Weinig | 30mm | 48mm | 158mm | 26mm | 100mm | FDHSK63WE02610030 |
| HSK63 Weinig | 30mm | 48mm | 178mm | 26mm | 120mm | FDHSK63WE02612030 |
| HSK63 Weinig | 30mm | 48mm | 188mm | 26mm | 130mm | FDHSK63WE02613030 |
| HSK63 Weinig | 30mm | 48mm | 198mm | 26mm | 140mm | FDHSK63WE02614030 |
| HSK63 Weinig | 30mm | 48mm | 238mm | 26mm | 180mm | FDHSK63WE02618030 |
| HSK63 Weinig | 40mm | 58mm | 108mm | 26mm | 50mm | FDHSK63WE02605040 |
| HSK63 Weinig | 40mm | 58mm | 138mm | 26mm | 80mm | FDHSK63WE02608040 |
| HSK63 Weinig | 40mm | 58mm | 158mm | 26mm | 100mm | FDHSK63WE02610040 |
| HSK63 Weinig | 40mm | 58mm | 178mm | 26mm | 120mm | FDHSK63WE02612040 |
| HSK63 Weinig | 40mm | 58mm | 188mm | 26mm | 130mm | FDHSK63WE02613040 |
| HSK63 Weinig | 40mm | 58mm | 198mm | 26mm | 140mm | FDHSK63WE02614040 |
| HSK63 Weinig | 40mm | 58mm | 238mm | 26mm | 180mm | FDHSK63WE02618040 |
| HSK63 Weinig | 40mm | 58mm | 298mm | 26mm | 240mm | FDHSK63WE02624040 |
| HSK63 Weinig | 50mm | 65mm | 108mm | 26mm | 50mm | FDHSK63WE02605050 |
| HSK63 Weinig | 50mm | 65mm | 138mm | 26mm | 80mm | FDHSK63WE02608050 |
| HSK63 Weinig | 50mm | 65mm | 188mm | 26mm | 130mm | FDHSK63WE02613050 |
| HSK63 Weinig | 50mm | 65mm | 228mm | 26mm | 170mm | FDHSK63WE02617050 |
