SK40 COLLET CHUCK
manufactured according to DIN69871, in the following sizes:
- ER32 (DIN6499, clamping range 3-20mm)
- ER40 (DIN6499, clamping range 4-26mm)
- OZ25 (DIN6388, clamping range 2-25mm)
Hardened and hard-turned, balanced, also available as a left-hand version.
Scope of delivery: without collet, with ball-bearing clamping nut and drawbar of your choice.
| Cone | Size | D | D1 | L1 | L2 | L3 | Article Number |
|---|---|---|---|---|---|---|---|
| SK40 | ER32 | 50mm | 63.5mm | 125.5mm | 60mm | 41mm | SPZ40DIN06032ERR |
| SK40 | ER40 | 63mm | 63.5mm | 138.5mm | 70mm | 51mm | SPZ40DIN07040ERR |
| SK40 | OZ25 | 60mm | 63.5mm | 138.5mm | 70mm | 51mm | SPZ40DIN07025OZR |
