HSK63F COLLET CHUCK
according to DIN69893-6, in the following sizes:
- ER32 (DIN6499, clamping range 3-20mm)
- ER40 (DIN6499, clamping range 4-26mm)
- OZ25 (DIN6388, clamping range 2-25mm)
Hardened and hard-turned, balanced, left-hand version available on request
Scope of delivery: without collet, with ball-bearing clamping nut.
Cone | Size | D | D1 | L1 | L2 / A | L3 | Article Number |
|---|---|---|---|---|---|---|---|
| HSK63F | ER32 | 50mm | 63mm | 95mm | 70mm | 44mm | SPZHSK63F07032ERR |
| HSK63F | ER32 | 50mm | 63mm | 125mm | 100mm | 74mm | SPZHSK63F10032ERR |
| HSK63F | ER40 | 63mm | 63mm | 101mm | 76mm | 51mm | SPZHSK63F07640ERR |
| HSK63F | ER40 | 63mm | 63mm | 115mm | 90mm | 64mm | SPZHSK63F09040ERR |
| HSK63F | OZ25 | 60mm | 63mm | 101mm | 76mm | 50mm | SPZHSK63F07625OZR |
| HSK63F | OZ25 | 60mm | 63mm | 105mm | 80mm | 54mm | SPZHSK63F08025OZR |
| HSK63F | OZ25 | 60mm | 63mm | 140mm | 115mm | 89mm | SPZHSK63F11525OZR |
